The Infinity 8 control panel is housed in the most attractive, modern designed, flame retardent ABS nclosure, utilising a switch mode power supply. It has a fully removable front cover which improves ease of access for cable installations. The Infinity 8 panel can also be ordered with a metal back box facilitating upto 7ah batteries to fit within the panel housing. To order this version add “/M” to the end of the model number (i.e. IN1/M, IN2/M, etc.)
| Model | IN1 | IN2 | IN4 | IN6 | IN8 |
|---|---|---|---|---|---|
| Part No | 37-650 | 37-651 | 37-652 | 37-653 | 37-654 |
| Mains Voltage | 230V AC +10% / -15% @ 50/60 Hz | ||||
| System Voltage | 24V DC (Nominal) | ||||
| Zone Voltage | 21V DC (Nominal) | ||||
| Sounder Alarm Output | 2 x 150mA @ 24V DC 4 x 150mA @ 24V DC | ||||
| Fault Relay | 1 x Volt Free Relay, SELV @ 1A Max | ||||
| Fire Relay | 1 x Volt Free Relay, SELV @ 1A Max | ||||
| Zone Capacity | 32 devices per zone | ||||
| Remote sounder operation | Via N/O contact connected to Class Change | ||||
| Sounder Activation Delay | 0 to 10 minutes in 1 minute increments | ||||
| Zone End of line | 1N4002 Diode (Cathode Stripe to Zone +ve) | ||||
| Sounder End of Line | 10K resistor | ||||
| Charger Voltage | 27.6V | ||||
| Battery cut off | Battery voltage less than 20V | ||||
| Battery Internal Resistance limit | 0.9 ohm | ||||
| Enclosure size | 371 x 302 x 93 (mm) | ||||
| Weight | 3 kg (Excluding Batteries) | ||||
| Maximum battery space | 2 x 3.4 Ah, 12 Vdc sealed lead acid | ||||
